Fishtail End Forging Machine (EF02)

Creative_HotProcess_Fishtail_Model

Elegant_EndForging_Sculpting

Fishtail_Model_EndForging

HotProcess_Fishtail_Forging_Craft

acil_butonu

reduktor and motor

This fishtail end forging machine uses two gear-driven, synchronized angled molds to taper the ends of hot iron into a chisel-like fishtail point. It processes flat (rectangular) bar, square bar, or round bar — with a maximum flat bar width of 60 mm and a maximum material thickness or diameter of 18 mm.

⚙️ GEARED TWIN-MOLD DESIGN

Two synchronized, angled molds driven by gears shape both sides of the heated iron end simultaneously, producing a clean, consistent fishtail forging every cycle.

🔩 FLAT, SQUARE & ROUND BAR

Works with flat bar up to 60 mm wide, or square/round bar up to 18 mm thick/in diameter — one machine covers multiple stock types.

Iron must be heated before processing, using either induction heating or a furnace. Powered by a 380V, 4 kW motor at 32 RPM, and weighing 450 kg, this hot end forging machine is built for consistent daily workshop use.

📞 Need a fishtail end forging machine for your workshop? Contact us for pricing and specifications.

Machine EF02

Motor	380 Volt - 3 Phase - 4 kW - 32 Revolutions/minute
Dimensions (Width x Length x Height cm.)	117 x 78 x 120 cm
Weight kg	450kg
Maximum Material Thickness mm	18mm
Maximum Material Width mm	60mm
Operations that can be done with the machine	Scroll Bending Machine
Use of Hot Cold Material	Hot Iron
Warranty	Our product is under company warranty for 12 months from the date of delivery. Electrical components and the motor are not covered by the warranty. When necessary, Cengizler Machinery Company sends a technician to solve the problems. The customer is responsible for the technician's travel, accommodation, meals, daily allowance, and the transportation cost of the necessary spare parts.
Payment	%50 deposit, %50 before delivery
Delivery Conditions	Mersin Factory

The 4 Key Advantages of the Tip Crushing Machine (EF02).
✔ 2344 made in Germanymold material
✔ Suitable for thick plates and squares.
✔ You can crush the same iron several times
✔ Durable and heat-treated molds.

Why Should You Chose This Product?
✔ We paint the machine in the color of your choice.
✔ The emergency button is available in our machine for emergency situations.
✔ Tapered, CNC-machined mold design.
✔ We manufacture steel box for transportation, ensuring that your machinery remains undamaged during shipment.

The Most Popular Machine in Turkey. 4 Reasons
✔ Educational and Consulting Services: We provide training and consultancy services to customers for the correct and effective use of our products.
✔ We are proud: Our machines are operating in more than 50 countries.
✔ Professional After-Sales Support and Service: We offer after-sales support and service to our customers.
✔ The machine you purchase is covered by our companys warranty for 12 months.

Comments from Happy Customers :)
✔ "Bu makine işimde gerçekten bir devrim yarattı! Verimliliği artırdı ve iş akışımı büyük ölçüde iyileştirdi. Çok memnun kaldım!" - Mehmet Yılmaz
(This machine has truly revolutionized my work! It increased efficiency and greatly improved my workflow. I'm very satisfied! - Mehmet Yılmaz)
✔ "شكرًا، الجهاز قد ساهم كثيرًا في تحسين سير عملي!" - يوسف الغانم، دولة قطر
(Thank you, the machine has greatly helped improve my workflow! - Yousef Al-Ghanim, Qatar)

Top 100 Best Selling Machines Chosen by Customers

✔ User-Friendly Design, Saving Time and Energy!
✔ While our products provide high quality and reliability, we offer our customers economical solutions with competitive prices.
✔ Hundreds of references worldwide. And happy customers :)
✔ Affordable Spare Parts Service, Even if the Warranty Period Expires, We Still Support You!

"Order now to turn your dream wrought iron designs into reality and add a new dimension to your art!"
